NH2 gG NH FUSE LINK 500V DF ELECTRIC

DF ELECTRIC (MADE IN SPAIN)

DF is specialized in the manufacturing of fuse links & fuse holders since 1987.

Technical data

Item: NH2 FUSE

Rated voltage: 500V AC +5%

Rated currents: 63A...500A

Rated breaking capacity: 120kA

Utilization category: gG

Weight:  620gr

Rated frequency: 42...62Hz

Storage temperature: -40°C ... 90°C

Operating temperature: -40°C ... 80°C

VARIATIONS

315A 381370

400A 381380

NOTE: PLEASE FEEL FREE TO SEND ANY INQUIRY ABOUT YOUR REQUIREMENTS.
