16mm L.E.D INDICATION LAMPS / PILOT LAMPS FOR ELECTRICAL PANELS

AD16-16C series indicators used pure-color LED luminescent chip as light source with long service life and low energy consumption. Pilot lights and LED indicator lights are indicating lights for machines or instruments.They can be used to indicate when a machine or industrial process has started or stopped. They provide solutions for a variety of requirements and are ideal for highly reliable visual indication#

GENERAL SPECIFICATIONS:

Luminous Intensity: >60cd/m3.

Terminal Type: Screw on.

Operating Voltage: 220Vac

Frequency (AC): 50~60Hz.

Operating Current: <20mA.

Continuous Operating Life: >30,000H.

Insulation Withstand: 2.5kVac, 1 minute.

Panel Cut Out Diameter: Ø16mm.

NOTE: PLEASE FEEL FREE TO SEND ANY INQUIRY ABOUT YOUR REQUIRMENTS.
